Conductive Silicones: The Most Electrically Conductive Silicones for EMI Gaskets

These EMI shielding silicones have the highest level of electrical conductivity. They contain silver-coated particles.

Choose electrically conductive silicones sheets, rolls, moldable compounds, extrusions, EMI O-rings, or EMI gaskets.

Electrically Conductive Silicone Materials

SSP’s most conductive EMI shielding silicones have silver-coated particles and the highest level of electrical conductivity. They include QPL certified MIL-DTL-83528 Type A and Type K. There’s also a silver-aluminum silicone with optimum surface conductivity and a silver-nickel fluorosilicone for harsh environments.

CHO-SEAL 1298 alternative

SSP482-75

SSP482-75 is a 75-durometer, electrically-conductive, silver-nickel silicone shielding elastomer that’s designed to meet MIL-DTL-83528 Type L. Find out if this shielding silicone is right for your EMI RFI gaskets.

Read More »
MIL-DTL-83528C Type B EMI gasket material

SSP482F-75

SSP482F-75 is a 75-durometer, very conductive, silver-nickel fluorosilicone that combines EMI shielding with resistance to harsh environments.

Read More »

Electrically Conductive Silicones Explained

Silicone materials are widely regarded for their versatility and robustness in industrial and engineering applications. Among these, electrically conductive silicones represent a unique class of materials that combine the inherent advantages of silicones—such as flexibility, chemical resistance, and thermal stability—with the ability to conduct electricity.

For engineers, these materials open up a broad range of opportunities for innovative designs and solutions in electronics, telecommunications, automotive, aerospace, and medical devices. Learn more about the properties, types, applications, and considerations for using electrically conductive silicones.

Properties of Electrically Conductive Silicones

Electrically conductive silicones derive their functionality from their dual ability to insulate and conduct electricity. This is achieved by incorporating conductive fillers into the silicone matrix. The primary properties that make them appealing to engineers include:

  • Electrical Conductivity: By adding conductive particles such as silver, carbon, nickel, or gold, silicones can achieve varying levels of conductivity, ranging from semi-conductive to highly conductive.
  • Thermal Stability: Silicones remain stable over a wide temperature range, typically from -55°C to 200°C (and beyond in specialized formulations). This makes them ideal for environments with extreme thermal fluctuations.
  • Flexibility and Elasticity: These materials maintain their flexibility even at low temperatures, which is crucial for applications that involve mechanical stress or vibration.
  • Chemical Resistance: Silicones resist degradation from exposure to oils, solvents, and other harsh chemicals, ensuring long-term reliability in demanding environments.
  • Environmental Resistance: They are inherently resistant to UV radiation, ozone, and moisture, making them suitable for outdoor and high-humidity applications.
  • Adhesion and Formability: Electrically conductive silicones can be formulated as adhesives, pastes, coatings, or molded parts, allowing for versatility in manufacturing and integration.

Types of Electrically Conductive Silicones

Engineers have a wide array of electrically conductive silicones to choose from, depending on the application and performance requirements.

The main types include:

  • EMI/RFI Shielding Materials: Silicones filled with conductive particles like nickel-coated graphite or silver are used for electromagnetic interference (EMI) and radio frequency interference (RFI) shielding in electronic devices.
  • Thermal Interface Materials (TIMs): These materials combine thermal and electrical conductivity, serving as interfaces between heat-generating components and heat sinks or spreaders.
  • Conductive Elastomers: These flexible materials are often used in gaskets, seals, and keypads. Their combination of electrical conductivity and mechanical resilience makes them suitable for harsh environments.
  • Conductive Adhesives: These are used to bond components while ensuring electrical connectivity. Silver-filled silicone adhesives are common due to their excellent conductivity and corrosion resistance.
  • Carbon-Based Conductive Silicones: These are lightweight and cost-effective alternatives for applications requiring moderate conductivity, such as antistatic coatings and ESD (electrostatic discharge) protection.

Applications of Electrically Conductive Silicones

Electrically conductive silicones find applications across various industries, addressing challenges in electrical connectivity, thermal management, and environmental protection.

Electronics and Telecommunications:

    • EMI/RFI Shielding: Conductive silicones are used to shield sensitive electronic components from electromagnetic interference, ensuring signal integrity in devices such as smartphones, tablets, and communication equipment.
    • PCB Assembly: Conductive adhesives replace solder in certain PCB (printed circuit board) applications, providing a lead-free and flexible alternative.

Automotive and Aerospace:

    • Sealing and Shielding: Conductive silicone gaskets and seals protect electronic control units (ECUs), sensors, and other critical components from EMI and environmental factors.
    • Thermal Management: In electric vehicles (EVs) and aircraft, conductive silicones are used as thermal interface materials to manage heat dissipation from batteries and power electronics.

Medical Devices:

    • Wearable Electronics: Electrically conductive silicones enable flexible and biocompatible connections in wearable medical devices and sensors.
    • Implantable Devices: Conductive silicones are used in medical implants for electrical stimulation and signal transmission.

Energy Sector:

    • Solar Panels: Conductive silicones are employed for electrical interconnections and to enhance thermal management in photovoltaic modules.
    • Fuel Cells and Batteries: These materials contribute to sealing, electrical conductivity, and thermal performance in advanced energy systems.

Consumer Electronics

    • Touch Screens and Keypads: Conductive silicones are integral to the design of touch-sensitive and flexible input devices.
    • Antistatic Coatings: Carbon-filled silicones are applied as coatings to prevent static charge buildup in electronic devices.

Considerations for Using Electrically Conductive Silicones

While electrically conductive silicones offer numerous benefits, their selection and application require careful consideration to ensure optimal performance.

  • Conductivity Requirements: The level of conductivity needed will dictate the choice of filler material and its concentration. Silver offers high conductivity but is expensive, while carbon-based fillers provide moderate conductivity at a lower cost.
  • Mechanical Properties: The material’s flexibility, hardness, and tensile strength must align with the application’s mechanical demands.
  • Environmental Conditions: Applications exposed to harsh conditions, such as high temperatures, humidity, or corrosive environments, require specially formulated silicones.
  • Processing and Integration: The form factor (adhesive, coating, molded part) should be compatible with the manufacturing process. For instance, adhesives need to cure quickly in high-throughput environments, while molded parts require precise dimensional stability.
  • Cost Considerations: The choice of fillers and the formulation process can significantly impact the cost. Engineers must balance performance requirements with budget constraints.
  • Long-Term Reliability: Factors such as filler dispersion, material aging, and potential for galvanic corrosion (when using metallic fillers) must be evaluated to ensure durability over the product’s lifespan.

Emerging Trends and Innovations

The field of electrically conductive silicones is evolving rapidly, driven by advancements in materials science and the increasing demand for high-performance electronic and energy devices. Key trends include:

  • Nanotechnology: The use of nanomaterials, such as graphene and carbon nanotubes, enhances conductivity while maintaining flexibility and reducing weight.
  • Hybrid Materials: Combining silicones with other polymers or fillers enables tailored properties, such as improved thermal conductivity or enhanced mechanical strength.
  • Sustainable Formulations: Eco-friendly and recyclable conductive silicones are gaining attention as industries prioritize sustainability.
  • Miniaturization: As electronic devices become smaller and more complex, conductive silicones are being developed with finer fillers and improved processing techniques to meet these demands.
  • High-Temperature Applications: New formulations extend the thermal stability of conductive silicones beyond traditional limits, enabling their use in extreme environments.



Conductive Compounds, Conductive Elastomers & Conductive Silicone Rubber

  • Conductive compounds are materials that allow the flow of electricity (or heat).
  • Conductive elastomers consist of a polymer matrix that is mixed with electrically conductive fillers such as metal or metal-coasted particles.
  • Conductive silicone rubber is used in many EMI gaskets because it combines EMI shielding and electrical conductivity with environmental sealing, high and low temperature insulation, and thermal stability.

Conductive Gasket / Conductive Seal

Conductive gaskets are specialized sealing materials designed to provide electrical conductivity (or thermal conductivity) while also maintaining a physical barrier for environmental protection.

Electrically conducive gaskets are used in applications where both electromagnetic interference (EMI) shielding and environmental sealing are required. These conductive seals prevent the leakage of electromagnetic waves (which can interfere with electronic components) and block external EMI from entering sensitive devices.

What is a Conductive Gasket?

Conductive gaskets are often made of elastomers (like silicone or rubber) filled with conductive particles such as silver, nickel, or carbon. Some gaskets may also be made of metal mesh or fabric that is highly conductive.

Conductive Gasket Material Types

  • Elastomer-based gaskets: These are flexible and can accommodate irregular surfaces. The conductive fillers embedded in the elastomer allow it to conduct electricity while maintaining a seal.
  • Wire mesh gaskets: These are typically woven or knitted from metal wires like aluminum or copper. They provide excellent conductivity and EMI shielding.
  • Conductive fabric over foam: A foam core is wrapped with a conductive fabric, offering both flexibility and effective shielding.

Conductive Seal Applications

  • EMI/RFI Shielding: Used in electronic enclosures, shielding sensitive electronics from radio frequency interference.
  • Sealing: Provide environmental protection against dust, moisture, and other contaminants.
  • Grounding: Can create a low-resistance electrical path for grounding electronic devices.

Which Industries Use a Conductive Seal?

  • Aerospace
  • Telecommunications
  • Automotive
  • Medical devices
  • Military applications

Choose a Conductive Gasket or Conductive Seal from SSP

Conductive gaskets are crucial in electronics where electromagnetic compatibility (EMC) standards must be met. They offer both electrical and physical protection.

Contact SSP for more information.
