M83528/003 Type A Solid D EMI Gaskets (SSP2569-65)

Specialty Silicone Products (SSP) makes Type A M83528/003 Solid D EMI shielding gaskets from silver-copper silicones that we extrude at our Made in USA manufacturing facility.

Contact Us

Part Numbers & Dimensions: M83528/003 Type A Solid D EMI Gaskets

Specialty Silicone Products (SSP) manufactures Type A extruded M83528/003 Solid D EMI shielding gaskets from SSP2569-65, a 65-durometer silver-copper silicone that is part of the U.S. Defense Logistics Agency (DLA) Qualified Products List (QPL).

Mil-Spec Part Number (PIN)SSP Part NumberDim A (in / mm)Dim B (in / mm)Dim C (in / mm)Rec. Groove WidthRec. Groove Height

M83528/003A001

E2569-031-062-EXSD.031 / 0.78.062 / 1.57.068 / 1.73.065 / 1.65.051 / 1.29

M83528/003A002

E2569-047-094-EXSD.047 / 1.19.094 / 2.39.078 / 1.98.097 / 2.46.059 / 1.50

M83528/003A003

E2569-039-078-EXSD.039 / 0.99.078 / 1.98.089 / 2.26.080 / 2.03.066 / 1.67

M83528/003A004

E2569-047-094-EXSD.047 / 1.19.094 / 2.39.094 / 2.39.097 / 2.46.070 / 1.78

M83528/003A005

E2569-031-062-EXSD.031 / 0.78.062 / 1.57.100 / 2.54.065 / 1.65.075 / 1.90

M83528/003A006

E2569-031-150-EXSD.075 / 1.91.150 / 3.81.110 / 2.79.155 / 3.93.083 / 2.10

M83528/003A007

E2569-061-122-EXSD.061 / 1.55.122 / 3.10.135 / 3.43.125 / 3.17.101 / 2.56

M83528/003A008

E2569-059-118-EXSD.059 / 1.49.118 / 3.00.156 / 3.96.120 / 3.04.117 / 2.97

M83528/003A009

E2569-078-156-EXSD.078 / 1.98.156 / 3.96.156 / 3.96.160 / 4.06.117 / 2.97

M83528/003A010

E2569-089-178-EXSD.089 / 2.26.178 / 4.52.175 / 4.45.181 / 4.60.131 / 3.32

M83528/003A011

E2569-094-188-EXSD.094 / 2.39.188 / 4.78.188 / 4.78.193 / 4.90.141 / 3.58

M83528/003A012

E2569-125-250-EXSD.125 / 3.18.250 / 6.35.250 / 6.35.255 / 6.47.187 / 4.75

FAQs: M83528/003 Type A Solid D EMI Gaskets

What are the EMI shielding requirements for a MIL-DTL-83528 Type A material?

MIL-DTL-83528 Type A materials offer maximum attenuation (110 dB at 10 GHz) across a continuous temperature range of -55°C to +160°C.

Yes. SSP2569-65 is an alternative or offset to these materials:

SSP offers low minimum order quantities (MOQs) and fast turnaround times. Plus, you can buy from us directly.

In addition to MIL-DTL-83528 Type A, SSP makes these other materials for solid D EMI gaskets:

  • M83528/003 Type B
  • M83528/003 Type C
  • M83528/003 Type D
  • M83528/003 Type K
